Trek Marlin 7
Marlin 7 is where race-worthy mountain bikes begin. The smooth, lightweight RockShox fork and upgraded parts make this model the best choice for new riders who want a fast cross country hardtail that will hold its own against our higher-end race bikes.
Marlin 7 is where race-worthy mountain bikes begin. The smooth, lightweight RockShox fork and upgraded parts make this model the best choice for new riders who want a fast cross country hardtail that will hold its own against our higher-end race bikes.
Marlin 7 is where race-worthy mountain bikes begin. The smooth, lightweight RockShox fork and upgraded parts make this model the best choice for new riders who want a fast cross country hardtail that will hold its own against our higher-end race bikes.
FrameAlpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR*ForkSize: XS
RockShox Judy, coil spring, preload, TurnKey lockout, 42mm offset for 27.5" wheel, 100mm QR, 80mm travelSize: S
RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travelSize: M , ML , L , XL , XXL
RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travelMax compatible fork travel100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)
Wheels
Hub frontFormula DC-20, alloy, 6-bolt, 5x100 mm QRHub rearFormula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QRSkewer rear152x5mm QRRimBontrager Connection, double-wall, 32-hole, 20 mm width, Presta valveSpokes14g stainless steel*TireSize: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"Max tire sizeFrame: 29x2.20" (XS & S: 27.5x2.40"), Fork: See manufacturer
Drivetrain
ShifterShimano Deore M4100, 10 speedRear derailleurShimano Deore M5120, long cage*CrankSize: XS , S , M
FSA Alpha Drive, 28T steel ring, Boost, 170mm lengthSize: ML , L , XL , XXL
FSA Alpha Drive, 28T steel ring, Boost, 175mm lengthBottom bracketFSA, 73 mm, threaded cartridge, 122.5 mm spindleCassetteShimano Deore M4100, 11-46, 10 speedChainKMC X10, 10 speedPedalVP-536 nylon platformMax chainring size1x/2x: 34T, 3x: 42T
Components
SaddleBontrager Arvada, steel rails, 138 mm width*SeatpostSize: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm lengthSize: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length*HandlebarSize: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm widthSize: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm widthGripsBontrager XR Trail Comp, nylon lock-on*StemSize: XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm lengthSize: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm lengthSize: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm lengthSize: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm lengthSize: XL , XXL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm lengthHeadsetSemi-integrated, 1-1/8"BrakeShimano MT200 hydraulic disc*Brake rotorSize: XS , S , M , ML , L , XL , XXL
Shimano RT26, 6-bolt,160 mmSize: L , XL , XXL
Shimano RT26, 6-bolt,180 mmBrake SetShimano MT200 hydraulic disc
Weight
WeightM - 13.47 kg / 29.7 lbsWeight limitThis bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
