Trek Marlin 6
Marlin 6 is a cross country mountain bike built to give you an efficient off-road ride with a suspension fork that locks out, and a simple 1x drivetrain. It's made for mountain biking, but it's also equipped with features like rack and kickstand mounts that make it a great choice for adventurous daily commutes.
Marlin 6 is a cross country mountain bike built to give you an efficient off-road ride with a suspension fork that locks out, and a simple 1x drivetrain. It's made for mountain biking, but it's also equipped with features like rack and kickstand mounts that make it a great choice for adventurous daily commutes.
Marlin 6 is a cross country mountain bike built to give you an efficient off-road ride with a suspension fork that locks out, and a simple 1x drivetrain. It's made for mountain biking, but it's also equipped with features like rack and kickstand mounts that make it a great choice for adventurous daily commutes.
FrameAlpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR*ForkSize: XS
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5" wheel, 100mm QR, 80mm travelSize: S
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travelSize: M , ML , L , XL , XXL
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29" wheel, 100mm QR, 100mm travelMax compatible fork travel100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)
Wheels
Hub frontFormula DC-20, alloy, 6-bolt, 5x100 mm QRHub rearFormula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QRSkewer rear152x5mm QRRimBontrager Connection, double-wall, 32-hole, 20mm width, schrader valve*TireSize: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"Max tire sizeFrame: 29x2.20" (XS & S: 27.5x2.40"), Fork: See manufacturer
Drivetrain
ShifterShimano Deore M4100, 10 speedRear derailleurShimano Deore M5120, long cageCrankProwheel C10Y-NW, 30T steel narrow-wide ring, 170 mm lengthBottom bracketSealed cartridge, 73mmCassetteShimano Deore M4100, 11-46, 10 speedChainKMC X10, 10 speedPedalVP-536 nylon platformMax chainring size1x/2x: 34T, 3x: 42T
Components
SaddleBontrager Arvada, steel rails, 138 mm width*SeatpostSize: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm lengthSize: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length*HandlebarSize: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm widthSize: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm widthGripsBontrager XR Endurance Comp, lock-on*StemSize: XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm lengthSize: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm lengthSize: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm lengthSize: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm lengthSize: XL , XXL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm lengthHeadsetSemi-integrated, 1-1/8"BrakeTektro HD-M275 hydraulic discBrake SetTektro HD-M275 hydraulic disc, 160mm rotor
Weight
WeightM - 14.11 kg / 31.11 lbsWeight limitThis bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
